Mobile Pallet Racking (MOVO)

Introducing how we can increase your warehouse efficiency!

Moving premises can be costly and logistically challenging. That’s where MOVO our mobile pallet racking system comes in!

But what is MOVO?
Mobile racking is pallet racking mounted on rails. It's a dynamic, compact storage solution that offers total flexibility and is suitable for every type of goods. The condensed nature of the system creates extra space, maximises the storage area while retaining 100% accessibility. The laterally moveable racking runs are controlled by radio remote control or by pressing a button on the rack. When the racking opens an aisle is created for a forklift truck or automated guided vehicle to enter and pick the order, manual picking is also a possibility.

MOVO Mobile Pallet Racking from Dexion

Advantages of mobile racks

More storage – 80% more capacity than conventional pallet racking
Space saving – save up to 50% of the space required by conventional pallet racking
Accessibility – 100% individual pallet access
Versatility – suitable for all types of warehouse goods, including coils and long goods
Economical – cuts energy, operating and cleaning costs; allowing for a good ROI
Safety assured – safety is paramount with the host of audiable and visual features that come as standard
Cold storage – Guaranteed operational safety of -30°C; ideal for use in cold-storage rooms

What satisfied customers say

“The Dexion team were friendly and helpful - getting in contact was quick and easy, which was very welcome considering the short time span we had available! From the beginning of the project we were insured of “High-quality solutions and high-quality materials”, and it has definitely been so.”

Davy Van Poucke and Ellen Tournois - managers of Dely Waffles

MOVO - Mobile pallet racking offers two distinct advantages

MAXIMISE AVAILABLE SPACE

Increase the storage capacity by up to 80%
Optimal use of floor space

MINIMISE STORAGE AREA

Streamline operations by reducing the footprint of the storage area
Gain over 50% more operating area for efficiency

3 reasons to choose MOVO mobile pallet racking

FLEXIBLE

Customer tailored solutions

DURABLE

Robust materials and advanced technology used for long-term reliability and safety

SAFE

Access monitoring with safety light barriers protects people

Mobile Pallet Racking is the perfect solution in cold stores

95% of all European cold stores are equipped with mobile racking

Reduced energy and operating costs
The light control system makes sure that only the open aisle is illuminated
Guaranteed operational safety of -30°C
Automating freezer warehouses and keeping lift trucks inside the freezer can reduce energy consumption
Manual control by remote control or existing warehouse management systems

Mobile Pallet Racking is the perfect solution in cold stores

MOVO Mobile pallet racking applications

Technical Specifications and Features

60T

Built for demanding warehouse environments, MOVO can handle heavy pallet loads with ease. Up to 60 tonnes per base.

15M

Designed to make the most of your vertical space MOVO racking can be built up to 15 metres high. This helps you store more without needing to expand your warehouse footprint.

90M

Can be configured with aisle lengths up to 90 metres, offering a scalable solution for high-density storage while ensuring structural integrity, safety, and smooth mobility.

Mobile racking controls: at the touch of a button

A range of control options are available to meet all requirements:

Light control – only the open aisle is lit
Commission mode – open pre-selected aisles
Night position – even spread – improves air circulation
Sprinkler position – a mode for fire protection
Picking position – multiple aisles partially open for access
Remote control – diagnostic and maintenance from experts
Aisle selection via radio control – remote controlled aisle selection saves time as the fork lift truck driver can open the aisles before arrival

Operating the MOVO can be done either from the central pilot control, from controls on each trolley or via remote radio control.

Mobile racking safety features

Acoustic warning before each movement
Flashing light during the whole movement process
Emergency stop buttons on each trolley
Complete safeguarding of the MOVO area by a multi-beam access control
Local safeguarding of the single trolleys by bidirectional lightbarriers in the foot areas

Software & Connectivity

ERP SYSTEM

We support and advise on setting up the interface between ERP and WMS.

With the GOpus® eBusiness solution, we offer you the option of connecting to SAP systems.

WAREHOUSE MANAGEMENT

The choice is yours!

Easily integrated into your WMS.

MOVO CONTROL

MOVO Control receives requests and controls the mobile rack.

Service & Maintenance

SECURE YOUR BUSINESS WITH SERVICE PACKAGES

Maintained service history, tracking the maintenance history and repairs.

PREDICTIVE MAINTENANCE

Address potential problems before they escalate into major breakdowns. Minimising repair costs and downtime.

Serviced and inspected by qualified, experienced technicians.

REMOTE SUPPORT

For quick and efficient trouble shooting, reducing downtime and the need for onsite visits.

Is mobile pallet racking cost efficient? - Based on 1000kg Europallet

23%

Increase in your investment

33%

Cheaper pallet places

80%

More storage capacity

*Based on 1000 kg Euro pallet

Automation Ready - Adaptable for a wide range of automation applications.

Dexion solutions are perfect for semi- and fully-automated warehouses, featuring manual racking systems like shelving, multi-tier, and pallet racks, along with automated small parts warehouses (AS/RS). They integrate seamlessly with picking robots, automated guided vehicles (AGVs), and storage and retrieval machines. Additionally, our WMS software TCPlus efficiently manages inventory and goods booking.

Your Mobile Racking Questions, Answered!

What is MOVO mobile racking?

MOVO is a high-density storage system where pallet racks are mounted on mobile bases that move along rails. This eliminates unnecessary aisles, significantly increasing storage capacity while maintaining 100% access to each pallet.

What are the advantages of MOVO mobile racking?

Up to 80% more storage capacity than conventional racking
50% less floor space required for the same volume of goods
100% individual pallet access
Energy-efficient, especially in cold storage
Safe operation with light barriers, emergency stop buttons, and access control
Flexible integration with manual or automated warehouse systems

How does MOVO improve warehouse efficiency?

MOVO reduces access times and increases throughput by optimizing space and material flow. It supports both manual and automated operation, making it ideal for dynamic inventory environments.

Is MOVO suitable for cold storage?

Yes. MOVO is designed to operate in temperatures as low as -30°C, making it perfect for cold and freezer storage. Its compact design also reduces the volume that needs cooling, saving energy.

Can MOVO be integrated with warehouse management software (WMS)?

Yes. MOVO can be integrated with your existing WMS. It also supports remote diagnostics and control for efficient operation.

What types of goods can MOVO store?

MOVO is suitable for a wide range of goods, including standard pallets, long items, reels, coils, and tyres. It’s ideal for low to medium rotation products and adaptable to various warehouse layouts.

What support does Dexion provide?

Dexion offers complete lifecycle support—from planning and installation to training, maintenance, and upgrades. Service packages include predictive maintenance and remote support to minimize downtime.

As a new service feature we offer an IoT based predictive maintenance support for MOVO.
